The main technical parameters
1. Dimensions: length 380mm×width 290mm×height 120mm
2. Net weight of host: 8Kg
3. Output power: 0-3000W
4. Output voltage: 0-3000V AC
5. Working environment temperature: +5°C to +50°C
6. Sine harmonic parameters: ≥97%
7. Input power factor: ≥80%
8. Working frequency: 15KHz/20KHz (optional)
9. Working power supply: AC220V 50Hz
10. Mould frequency range: ±400HZ (take 15KHZ ultrasonic as an example, the mould frequency can be used for automatic frequency tracking within 14.40-15.20KHZ.)
11. Automatic frequency tracking accuracy: ±5HZ
12. Power stability: ≤ 5%
13. When the remote terminal dynamically responds: ≤10ms
14. Overcurrent protection current: 15A
15. Overcurrent protection time: 100ms
16. Overheating protection temperature: 85℃
Q&A:
[Normal](Equipment Normal):Equipment is operating normally;
[Measuring](Measuring Frequency):Display when sweeping;
[No UT ](Transducer Unconnected):The transducer is not connected, or the transducer is damaged;
[Scan Fail](Failure of sweep):The transducer or horn may be damaged;
[Impedance Anomaly](Impedance Abnormal):This indicates that the impedance of the transducer is special and needs to be adjusted separately;
[Over Load](Output Overload):The die welding tool part(Transducer and horn) is abnormal, and the pressure may be too large. Try to reduce the amplitude or reduce the air pressure appropriately.
[Freq.Protect](Frequency Protection):This is generally because the frequency deviation of the die welding tool(Transducer and horn) is too large;
[SYS.Protect](Power Protection):If this happens many times, you have to contact the manufacturer, maybe the power transistor is broken.
